Full Electric Stacker

Short Description:

Full Electric Stacker is an electric stacker with wide legs and a three-stage H-shaped steel mast. This sturdy, structurally stable gantry ensures safety and stability during high-lift operations. The fork's outer width is adjustable, accommodating goods of varying sizes. Compared to the CDD20-A ser


Technical Data

Product Tags

Full Electric Stacker is an electric stacker with wide legs and a three-stage H-shaped steel mast. This sturdy, structurally stable gantry ensures safety and stability during high-lift operations. The fork's outer width is adjustable, accommodating goods of varying sizes. Compared to the CDD20-A series, it boasts an increased lifting height of up to 5500mm, making it ideal for handling and storing goods on ultra-high-rise shelves. The load capacity has also been increased to 2000kg, meeting the demands of heavy goods handling.

Additionally, the stacker can be equipped with a user-friendly arm guard structure and folding pedals, offering enhanced operator safety. Even first-time users can quickly adapt and enjoy an efficient, comfortable stacking experience.

Technical Data

Model



CDD-20

Config-code

W/O pedal& handrail



AK15/AK20

With pedal& handrail



AKT15AKT20

Drive Unit



Electric

Operation Type



Pedestrian/Standing

Load capacity(Q)

Kg

1500/2000

Load center(C)

mm

500

Overall Length (L)

mm

1891

Overall Width (b)

mm

1197~1520

Overall Height (H2)

mm

2175

2342

2508

Lift height (H)

mm

4500

5000

5500

Max working height(H1)

mm

5373

5873

6373

Free lift height(H3)

mm

1550

1717

1884

Fork dimension (L1*b2*m)

mm

1000x100x35

MAX Fork Width (b1)

mm

210~950

Min.aisle width for stacking(Ast)

mm

2565

Turning radius (Wa)

mm

1600

Drive Motor Power

KW

1.6AC

Lift Motor Power

KW

3.0

Battery

Ah/V

240/24

Weight w/o battery

Kg

1195

1245

1295

Battery weight

kg

235

Specifications of Full Electric Stacker:

The CDD20-AK/AKT series fully electric stackers, as an upgraded version of the CDD20-SK series, not only maintain the stable wide-leg design but also deliver a significant leap in core performance, setting a new benchmark for modern warehousing and logistics. The standout feature of this stacker is its three-stage mast, which dramatically increases the lifting height, allowing it to reach up to 5500mm with ease. This enhancement meets the demands of ultra-high-rise shelving, offering unprecedented flexibility and efficiency in logistics operations.

In terms of load capacity, the CDD20-AK/AKT series excels as well. Compared to the previous CDD20-SK series, its load capacity has been upgraded from 1500kg to 2000kg, enabling it to handle heavier goods and a wider variety of handling tasks. Whether it's heavy machinery parts, large packaging, or bulk goods, this stacker handles it effortlessly.

The CDD20-AK/AKT series also retains two driving modes—walking and standing—to suit different operators' preferences and working environments.

The adjustable fork width ranges from 210mm to 950mm, allowing the stacker to accommodate various types of cargo pallets, from standard sizes to custom pallets.

In terms of power, the series is equipped with a 1.6KW drive motor and a 3.0KW lifting motor. This powerful output ensures smooth and efficient operation under diverse working conditions. With an overall weight of 1530kg, the stacker is built to last, reflecting its robust and durable construction.

For safety, the stacker is equipped with comprehensive safety features, including an emergency power-off button. In case of an emergency, the operator can quickly press the red power-off button to immediately cut off power and stop the vehicle, effectively preventing accidents and ensuring the safety of both operators and goods.
