Crawler Scissor Lift Price

Short Description:

Crawler scissor lift price, as an advanced aerial work platform, plays a vital role in various industrial and commercial fields due to its unique design and excellent performance. The tracked scissor lift platform, equipped with support legs, utilizes automatic hydraulic outrigger technology. These


Technical Data

Product Tags

Crawler scissor lift price, as an advanced aerial work platform, plays a vital role in various industrial and commercial fields due to its unique design and excellent performance. The tracked scissor lift platform, equipped with support legs, utilizes automatic hydraulic outrigger technology. These outriggers are not only sturdy but also automatically adjust to uneven ground conditions, ensuring the equipment maintains a stable working posture in even the most challenging environments, providing a safe and reliable workspace for the operator.

The lifting mechanism at the core of the electric crawler scissor lift relies on an efficient hydraulic system, which drives the hydraulic cylinders via a motor to enable smooth platform lifting and lowering. This process is not only fast but also highly precise, meeting the operational needs of varying heights and angles. Additionally, the hydraulic system significantly enhances the equipment's load capacity and durability, ensuring stability and reliability for long-term use.

To enhance operational flexibility, crawler scissor lifts are designed with dual control panels. One control panel is located on the platform, allowing the operator to control both the lifting and movement of the equipment directly, thus improving work efficiency. The second control panel is located at the base of the equipment, providing convenience for ground personnel or during emergencies. A thoughtful feature is the interlocking mechanism between the two control panels, ensuring that only one panel is active at a time, effectively preventing misoperation and ensuring the safety of both operators and equipment.

Technical Data

Model

DXLDS 06

DXLDS 08

DXLDS 10

DXLDS 12

Max platform height

6m

8m

9.75m

11.75m

Max working height

8m

10m

12m

14m

Platform size

2270X1120mm

2270X1120mm

2270X1120mm

2270X1120mm

Extended platform size

900mm

900mm

900mm

900mm

Capacity

450kg

450kg

320kg

320kg

Extended platform load

113kg

113kg

113kg

113kg

Product size

(length*width*height)

2782*1581*2280mm

2782*1581*2400mm

2782*1581*2530mm

2782*1581*2670mm

Weight

2800Kg

2950kg

3240kg

3480kg

1214LD液压支腿_0032_IMG_4740
